Description
The 12th Gen Intel® Core™ processors feature a new hybrid performance architecture, delivering a unique combination of performance and efficiency cores. With the P Core and E Core, you'll enjoy scalable performance for any task.
Ideal for gaming and work without compromising performance. With its hybrid architecture of up to eight performance cores and eight efficiency cores, it delivers superior performance for tasks like streaming, browsing, editing, and video conferencing.
It features improved productivity with support for PCIe Gen 5.0 and 4.0, as well as DDR5 and DDR4. With Intel Laminar RM1 included in the box and compatibility with 600-series processor motherboards based on 58W chipsets, this processor offers increased efficiency for optimal performance. Requires discrete graphics.
It delivers high performance at an affordable price with its 3.30 GHz speed and hyperthreaded architecture. With 12 MB of L3 cache, data is retrieved quickly to improve system performance. It also features an integrated Intel UHD Graphics 730 controller for improved graphics quality and support for up to four monitors.
Technical Sheet
Specification | Detail |
---|---|
Processor manufacturer | Intel |
Processor model | Intel Core i5-12400 |
Architecture | Hybrid (P cores + E cores) |
Processor base frequency | 3.30 GHz |
Maximum turbo frequency | Up to 4.40 GHz (approximately, depending on model) |
Number of processor cores | 6 Cores (6 P-Cores, no E-Cores on this model) |
Number of threads | 12 |
Processor socket | LGA 1700 |
Processor lithography | Intel 7 (10 nm) |
Processor cache | 12 MB Intel Smart Cache (L3) |
Type of cache in processor | L2 + L3 cache |
Operating processor mode | 64-bit |
Thermal Design Power (TDP) | 65 W |
Integrated graphics | Intel UHD Graphics 730 |
Base graphics frequency | 300 MHz |
Maximum graphics frequency | Up to 1.45 GHz |
Maximum number of screens | Up to 4 |
Compatible memory | DDR4-3200 / DDR5-4800 |
Maximum memory capacity | 128 GB |
Maximum number of memory channels | 2 (dual channel) |
Maximum memory bandwidth | Up to 76.8 GB/s (with DDR5) |
PCI Express Review | 5.0 and 4.0 compatible |
PCI Express Configurations | Up to 1x16 + 1x4 |
Maximum number of PCI Express lanes | 20 |
Intel Hyper-Threading Technology | Yeah |
Intel Turbo Boost Technology 2.0 | Yeah |
Intel UHD Graphics 730 | Integrated, compatible with DirectX 12 and OpenGL 4.5 |
Supported technologies | Intel VT-x, VT-d, Intel 64, Execute Disable Bit |
Refrigeration | Includes Intel Laminar RM1 |
Motherboard compatibility | 600 series chipsets (H610, B660, Z690, etc.) |
Requires discrete graphics | Not necessarily (only if you purchase the "F" version, such as i5-12400F) |
